Wall Panels
McMillan Insulated Panels’ wall panels are the best solution for your vertical enclosures. They are suitable for facades and interior walls, with a high aesthetic value and excellent performance. McMillan Insulated Panels’ wall panels have high mechanical resistance, thermal insulation and fire resistance (up to 4-hours) thanks to their high-density mineral wool core type M (120 kq/m3; 7.5 lb/ft3). They can easily meet the functional, design and image requirements of your project.
Our wall panels consist of two steel sheets bonded by organic adhesive to, creating a strong and light structure. They are easy to install and maintain, and ideal for large industrial or civil building projects.
Our mineral wool wall panels are made with advanced technology and innovation.
They have a unique joint design that hides the fixings while ensuring a tight seal and weatherproofing when installed vertically or horizontally, which provides great architectural and technical advantages.
With McMillan Insulated Panels’ wall panels, you can benefit from exceptional thermal insulation for your building, helping you reduce energy consumption, improve indoor comfort, and protect the environment. Furthermore, our industry-leading mineral wool wall panels can withstand up to 4-hours (240 minutes, EI240) of fire exposure, preventing the flames from spreading and the structure from collapsing.
These panels also have great acoustic properties, thanks to the micro-perforations and fiberglass veil on the inner face of the panels that enhances the adhesion of the steel sheet and the absorption of sound waves, creating a quieter and more pleasant environment for your customers and employees.
Our mineral wool wall panels are designed with the user in mind, ensuring easy installation. The lightweight nature of the panels, combined with their modular design, allows for quick assembly.
This easy installation process not only saves time but also reduces construction costs, making it an ideal solution for both industrial and civil construction projects.
Choose McMillan Insulated Panels’ wall panels, the mineral wool insulated metal panels that combine functionality, aesthetics, and superior performance. Reach out to us for professional advice to bring your vision to life with confidence.
Fire Reaction Classified as A2-s1, d0 according to EN-13501-1 standard.
Permeability under pressure according to EN 12114:
+600PA: 0.66 m³/h·m²
-600PA: 0.96 m³/h·m²
Resistance to rainwater under air pressure impulses according to EN 12865: Classification 600A
Advantages of our Mineral Wool Wall Panels
Mineral wool is Fire-resistant:
Mineral wool walls are known for their excellent resistance against fire. This insulating mineral wool, thanks to its heat-resistant structure, acts as an effective barrier that slows down the spread of flames in case of fire. This provides greater security and protection in buildings and structures where an adequate response is required in emergency situations.
Durability:
Mineral wool walls are very durable and offer a long service life. Thanks to their resistance to moisture, rot, and damage caused by insects or fungi, they maintain their structural integrity for many years. This reduces the need for frequent replacement and contributes to long-term savings in maintenance costs.
Mineral Wool Thermal Insulation:
Mineral wool walls provide excellent thermal insulation. Their porous structure and their ability to retain the air trapped inside help to minimize heat transfer, keeping a more stable temperature inside the buildings. This allows for better temperature control, reduces the need for excessive heating or cooling systems, and ultimately helps to reduce energy costs.
Mineral Wool Acoustic Insulation:
Another outstanding benefit of mineral wool walls is their ability to provide excellent acoustic insulation. Thanks to their fibrous and porous structure, they absorb and dissipate sound waves efficiently, reducing noise propagation between different spaces. This contributes to the creation of more peaceful and comfortable environments, especially in residential, commercial, and educational buildings where noise interference from the outside or between rooms is sought to be minimized.
Another outstanding benefit of mineral wool roofs is their ability to provide excellent acoustic insulation. Thanks to their fibrous and porous structure, they absorb and dissipate sound waves efficiently, reducing noise propagation between different spaces. This contributes to the creation of more peaceful and comfortable environments, especially in residential, commercial, and educational buildings where noise interference from the outside or between rooms is sought to be minimized.
Installation Efficiency
Known for their ease and speed of assembly, our panels boast a modular design and simple connection system. This allows for efficient installation, reducing both installation time and associated costs.
Types of Mineral Wool Wall Panels
Concealed Fastener Wall Panels
Our insulated wall panels with concealed fastening, thanks to their joint design, guarantee complete watertightness of the union, whether installed vertically or horizontally. This innovative system ensures a flawless finish and superior performance for any facade application.
Concealed Fastener Acoustic Wall Panels
Preserving the characteristics of the concealed fixation panel, we have developed a product for specific situations that demand high acoustic absorption to achieve superior sound insulation.
By combining the absorbing effect of mineral wool with the appropriate perforations in the profile, we have created acoustic panels that significantly reduce noise exposure. This innovation reflects our commitment to providing solutions that enhance both the acoustic comfort and functionality of your spaces.
Exposed Fastener Wall Panels (Sectorization)
The design and development of the tongue-and-groove acoustic wall panel represent a breakthrough in acoustic sectorization for industrial or leisure construction. This acoustic panel achieves remarkable sound insulation and absorption, a combination not easily found in a single product. It stands as a testament to our commitment to innovation and excellence in acoustic solutions.
Exposed Fastener Acoustic Wall Panels (Sectorization)
The design and development of the tongue-and-groove acoustic wall panel represent a breakthrough in acoustic sectorization for industrial or leisure construction. This acoustic panel achieves remarkable sound insulation and absorption, a combination not easily found in a single product. It stands as a testament to our commitment to innovation and excellence in acoustic solutions.
Polyurethane (PUR) and Polyisocyanurate (PIR) Wall Panels
McMillan Insulated Panels’ wall installation solutions merge top-tier functionality, design, and aesthetics to meet the demands of contemporary projects, bringing our expertise and quality to the forefront.
Our wall panels are vertical enclosure solutions for main walls or other building areas, offering high aesthetic value and excellent mechanical and thermal resistance.
Our polyurethane (PUR) and/or polyisocyanurate (PIR) sandwich panels are designed for industrial, commercial, or residential walls, delivering architectural beauty and robust security and insulation.
The panel’s rigid foam core and steel faces provide formidable mechanical strength. These sandwich panels meet the highest thermal insulation standards, promoting energy savings and comfort.
With a concealed fixing profile, the panels ensure watertightness and protect fixings in any position. We offer various finishes—standard, flat, semi-flat, and micro-ribbed—to suit each project or client’s needs.
Ideal for facades, roofs, false ceilings, interior partitions, and refrigeration chambers, these products are versatile in application.
Expert advice will streamline your exterior facade panel construction and installation project, ensuring safety, speed, and cost-efficiency. Reach out to us for professional advice to bring your vision to life with confidence.
